0.6/1kV聚氯乙烯绝缘聚氯乙烯护套电力电缆

绞线；Stranded conductor 相对导电率58%； Relative conductance :58% IACS 铝合金；Aluminum alloy 耐热；Thermal resistan 钢芯绞线；Steel –reinforced stranded conductor 相对导电率58%； Relative conductance :58% IACS 铝合金；Aluminum alloy 耐热；Thermal resistant

用途：

变频电缆（又名变频电力电缆）广泛应用于变频器与电动机之间的电力线路上，实现电动机的无极调速。电缆的额定电压为0.6/1kV~3.6/6Kv,变化的变频为0Hz~400Hz或0Hz~61Hz，使电动机的转速由低速调到高速快速平衡的调制。

Power supply conversion cable is widely used in power supply,circuit between frequency converter

and electric motor so as to realize stepless speed regulation of electric motor.With rated voltage of

0.6/1kV ~3.6/6Kv, changing frequency from 0Hz to 400Hz or from 0Hz to 610Hz, the cable

Allows the rotational speed of electric motor to vary from low to high quickly and steadily.

特种：

变频电缆的特征有三相主线芯和三条中性线芯对称分布，并有两层屏蔽体，即内层总屏蔽和外层总屏蔽。

Power supply conversion cable has three-phase master line cores and three neutral cores,which

array symmetrically,and has two shielding bodies, namely, the inner layer general and outer

layer general shield.
